STPS20H100CGY-TR

Name: STMicroelectronics STPS20H100CGY-TR
Brand: STMicroelectronics
SKU: 511-STPS20H100CGY-TR
Price: 1.57 USD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

511-STPS20H100CGY-TR

Mfr. No:

STPS20H100CGY-TR

Mfr.:

STMicroelectronics

Description:

Schottky Diodes & Rectifiers Automotive 100 V, 20 A dual Power Schottky Rectifier

Complete Your Design

Datasheet:

STPS20H100CGY-TR Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about STMicroelectronics STPS20H100CGY-TR

Add To Project

Add Notes

In Stock: 2,952

Stock:: 2,952 Can Dispatch Immediately

An unexpected error occured.Please try again later.
Factory Lead Time:: 25 Weeks Estimated factory production time for quantities greater than shown.

Minimum: 1 Multiples: 1

Enter Quantity:

Unit Price:

$-.--

Ext. Price:

$-.--

Packaging:

Full Reel (Order in multiples of 1000)

Cut Tape

MouseReel™ (+$7.00)

Pricing (USD)

Qty.	Unit Price	Ext. Price
Cut Tape / MouseReel™ ^†
	$1.57	$1.57
	$1.06	$10.60
	$0.877	$87.70
	$0.682	$341.00
Full Reel (Order in multiples of 1000)
	$0.555	$555.00
	$0.554	$1,108.00

† A MouseReel™ fee of $7.00 will be added and calculated in your basket. All MouseReel™ orders are non-cancellable and non-returnable. ↩

Products found:

To show similar products, select at least one checkbox

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	STMicroelectronics
Product Category:	Schottky Diodes & Rectifiers
RoHS:
Product:	Schottky Rectifiers
Mounting Style:	SMD/SMT
Package/Case:	D2PAK-3 (TO-263-3)
Configuration:	Dual Anode Common Cathode
Technology:	Si
If - Forward Current:	20 A
Vrrm - Repetitive Reverse Voltage:	100 V
Vf - Forward Voltage:	880 mV
Ifsm - Forward Surge Current:	250 A
Ir - Reverse Current:	6 mA
Maximum Operating Temperature:	+ 175 C
Series:	STPS20H100C-Y
Qualification:	AEC-Q101
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Brand:	STMicroelectronics
Product Type:	Schottky Diodes & Rectifiers
Factory Pack Quantity:	1000
Subcategory:	Diodes & Rectifiers
Vr - Reverse Voltage:	100 V
Unit Weight:	1.480 g

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Datasheet

STPS20H100CGY-TR Datasheet (PDF)

PCN

CNHTS:: 8541590000
CAHTS:: 8541100090
USHTS:: 8541100080
JPHTS:: 854110090
KRHTS:: 8541109000
TARIC:: 8541100000
MXHTS:: 8541100101
ECCN:: EAR99

Standard Products

STMicroelectronics Standard Products are a broad range of industry-standard and drop-in replacements for the most popular general-purpose analog ICs, discretes, and serial EEPROMs. The Standard Products are manufactured to the highest quality standards with many AECQ-qualified for automotive applications. A comprehensive set of design aids, including SPICE, IBIS models, and simulation tools, are available to make adding to a design-in easy.

Automotive Power Schottky Diodes

STMicroelectronics Automotive Power Schottky Diodes combine low voltage-drop characteristics with negligible or zero recovery. They range from 30 to 170V and from 1 to 80A, so covering all application needs from OR-ing and 48V converters, to battery chargers and welding equipment. These devices feature a broad package offering, with through-hole and surface mount industry standard outlines, as well as the PowerFLAT™ package. This selection of power Schottky diodes are designed to meet the strict requirements of the automotive industry and are AEC-Q101 qualified.
