KYOCERA AVX Hermaphroditic WTW & WTB Connectors

KYOCERA AVX Hermaphroditic Wire-to-Wire (WTW) and Wire-to-Board (WTB) Connectors are designed for reliable electrical connections, supporting 18AWG to 16AWG solid or stranded wires on a 5mm pitch. The connectors feature plastic latches that provide strong mechanical retention, while the hermaphroditic design offers simplified mating. The 9288-000 series is available in configurations of 2 to 4 positions with tin-over-nickel plating for enhanced durability. Additional features include 6A or 7A current rating per contact and an operating temperature range of -40°C to +130°C. These hermaphroditic connectors from KYOCERA AVX are ideal for applications requiring robust and flexible interconnect solutions, including WTW, WTB, and field terminations.
