ams OSRAM OSLON® Signal High Power Signaling LEDs

ams OSRAM OSLON® Signal High Power Signaling LEDs offer a broad color portfolio in a robust and reliable compact package of 3mm x 3mm². The OSLON Gen 2 Signaling LEDs feature ThinFilm and UX:3 chip technology allowing high efficiency and high flux output with brightness increased up to 46% compared to the first generation.

The ams OSRAM OSLON Signal High Power Signaling LEDs have an electrically insulated thermal pad with easy thermal management for stable performance at high power levels. The broad color portfolio includes red, super red, verde, true green, yellow, blue, deep blue, and white that meets industry color standards.

Features

  • Color bins are defined for best fit to most signaling norms
  • Compact ceramic package with silicone lens (3mm x 3mm²)
  • Square package with optical center in the mechanical center
  • Enables customized high density clustering
  • Electrically insulated thermal pad
  • 120° Lambertian radiation angle

Applications

  • Signaling
  • Emergency vehicle lighting
  • Aviation
  • Transportation and industry

Application Diagram

ams OSRAM OSLON® Signal High Power Signaling LEDs

Block Diagrams

Block Diagram - ams OSRAM OSLON® Signal High Power Signaling LEDs

Videos

Associated Product

ams OSRAM OSLON® Signal LCB CRBP.01 LEDs

Emit converted blue color and feature 120° typical radiation and 8kV ESD withstand voltage.

Learn Moreabout ams OSRAM OSLON® Signal LCB CRBP.01 LEDs View Productsrelated to ams OSRAM OSLON® Signal LCB CRBP.01 LEDs

Related Solutions

ams OSRAM Factory Automation Solutions

Uses smart light and sensor solutions to guarantee functional safety in an open work environment.

Learn Moreabout ams OSRAM Factory Automation Solutions
View Results ( 7 ) Page
Part Number Datasheet Description Illumination Colour If - Forward Current Wavelength/Colour Temperature Luminous Flux/Radiant Flux Vf - Forward Voltage
LB CRBP.01-GXHY-26-Y474 LB CRBP.01-GXHY-26-Y474 Datasheet Single Colour LEDs LB CRBP.01 Blue 350 mA 475 nm 50 lm 2.9 V
LCB CRBP.01-KXLX-3B6B-Y474 LCB CRBP.01-KXLX-3B6B-Y474 Datasheet Single Colour LEDs OSLON Signal LCB CRBP.01 - Converted Blue Blue 350 mA 101 lm 2.9 V
LB CRBP.01-HYKX-7B-Y474 LB CRBP.01-HYKX-7B-Y474 Datasheet Single Colour LEDs LB CRBP.01 Blue 350 mA 475 nm 50 lm 2.9 V
LT CRBP.01-KZLZ-36-Q525 LT CRBP.01-KZLZ-36-Q525 Datasheet Single Colour LEDs LT CRBP.01 Green 350 mA 528 nm 139 lm 2.65 V
LUW CRBP.01-LYMY-G4J4-Y474 LUW CRBP.01-LYMY-G4J4-Y474 Datasheet White LEDs LUW CRBP.01 White 350 mA 185 lm 2.9 V
LV CRBP.01-KXLY-AD-Q525 LV CRBP.01-KXLY-AD-Q525 Datasheet Single Colour LEDs LV CRBP.01 True Green 350 mA 505 nm 111 lm 2.85 V
LJ CRBP.01-JZLX-27-3A4A LJ CRBP.01-JZLX-27-3A4A Datasheet Single Colour LEDs LJ CRBP.01 Red 350 mA 625 nm 95.5 lm 2.15 V
